Hauptbeiträge | Main Articles

Modular Engineering Kit for Tunnel Construction

All over the world, private and freight traffic will continue to increase. According to the German Federal Statistical Office, even now more than half of all people live in cities and the surrounding areas. Globalisation and urbanisation are causing these infrastructure developments. As a result, people, raw materials and goods are being moved around more than ever before. Civil engineering is confronted with increasing demands; this includes structures for transport and utility networks. Tunnels and bridges are key elements. Such projects are normally tendered internationally. For business reasons, the bidding companies must be able to use reliable and exactly definable construction machines or formwork and scaffolding systems.

more
Nachrichten | News Germany

One year after the Incident: The Situation at the Rastatt Tunnel

One year after the incident of 12 August 2017, works are proceeding at the Rastatt Tunnel. The removal of the concrete plug in the east bore has been completed and the detailed investigation program was finished in September 2018. The evidence gathering and arbitration process agreed between the consortium Tunnel Rastatt (Hochtief and Züblin) and Deutsche Bahn to clarify the causes of the damage during tunnel driving will last until the start of 2019.

more
Nachrichten | News Italy

World Tunnel Congress Naples, May 3rd–9th 2019

The next World Tunnel Congress will be held in Naples from 3rd to 9th May 2019. The conference A key event for the engineering and geotechnical sectors linked to tunnelling, promoted by the International Tunnelling and Underground Space Association (ITA-AITES) and Società Italiana Gallerie (SIG). This WTC will be characterized by a distinctive and unique perspective due to the inclusion of themes suggested by the city of Naples and its context, and more generally by the Italian background.

more
Nachrichten | News Austria/Slovenia

Karawanken Tunnel: ASFINAG starts Construction of the second Tube

On September 18, 2018, ASFINAG (Austrian Motorway Authority) heralded in the complete further development of the Karawanken Tunnel with the ground-breaking ceremony on the A 11 Karawanken motorway. Thanks to this new structure cofinanced by the EU, the two-way section on the important north-south link between Austria and Slovenia will soon be a thing of the past. During the course of the next five years therefore, the second, almost 8 km long tube will be excavated from both sides.

more
Hauptbeiträge | Main Articles

Tunnelling under the Suez Canal in Port Said

In future, the road tunnel beneath the Suez Canal to the south of the city of Port Said in northern Egypt will link the Lower Egyptian mainland with the Sinai Peninsula. The tunnel project is part of the Egyptian government’s plan for the economic development of the Suez Canal region presented in 2014. Towards this end, President Abdel Fattah el-Sisi’s government is concentrating on international trade and building up the cities of Suez, Ismailia and Port Said. By constructing the road tunnel, the ongoing substantial delays resulting from having to cope with heavy-duty and passenger traffic on ferries are to be alleviated. This article deals with the construction of the two roughly 2.9 km long tunnel tubes with an external diameter of 12,60 m, in the proximity of Port Said under somewhat out of the ordinary circumstances.

more
Hauptbeiträge | Main Articles

Filder Tunnel and Tunnels to Ober- and Untertürkheim

The Filder Tunnel (Plan Approval Section/PFA 1.2) and the tunnels running to Ober-/Untertürkheim (PFA 1.6a) for the Stuttgart–Ulm rail project are being built by the ATCOST21 JV on behalf of the DB Stuttgart–Ulm GmbH. The Filder Tunnel’s two tubes will link Stuttgart’s new Central Station with the Filder Plain to the south of Stuttgart. The tunnels leading to Ober-/Untertürkheim connect the Central Station with the existing rail line in the Neckar Valley and the new railway yard at Untertürkheim. The article in tunnel 5/2018 provides an overview of the status of the works as well a preview of forthcoming construction measures.

more
Hauptbeiträge | Main Articles

GKI Hydroelectric Power Plant Project: Technical and contractual Challenges

In the border region between Switzerland and Austria, the largest hydroelectric run off river power station in the Alps, is being built in Engadine and in Tyrol on the upper reaches of the river Inn. With a 23 km headrace tunnel and a dam construction site directly on the border, apart from the technical challenges, there are also cross-border issues which have to be resolved. This article from tunnel 5/2018 was part of the conference programme at the Swiss Tunnel Congress 2018.

more
Interview

Two Generations of Tunnelling Interview with Dr.-Ing. E.h. Martin and Martin-Devid Herrenknecht

Herrenknecht AG is a globally successful family business with 5000 employees and the market leader, not only for tunnel boring machines. Since the founding of Herrenknecht GmbH in 1977 by – as described aptly in the company chronicle – “namesake, driving force and CEO” Dr.-Ing. E. h. Martin Herrenknecht, the company has developed dynamically and convinced again and again with technically sophisticated solutions to problems in underground construction. Meanwhile, Martin-Devid Herrenknecht, engineer and one of three children, has joined the company. Rarely does one have the opportunity to meet both father and son for a very personal interview with fascinating statements on the market, technologies and the future of tunnel construction.

more
Building Information Modeling

BIM Application Cases at the Albvorland Tunnel

In the “Albvorland Tunnel” section of the Stuttgart–Ulm rail project, some areas are being implemented with the assistance of Building Information Modeling. The following BIM application cases were defined: 3D-assisted design and collision detection (3D), linking of the schedule with the 3D model to check construction sequence and date collisions (4D), linking of the bill of quantities with the 3D model and the schedule (5D) to produce cost curve analyses and monitor construction progress and performance reports, reporting for the clear illustration of the significant key numbers to the BIM application cases.

more
Building Information Modeling

New Gubrist Tunnel: A Case for BIM

The 3.25 km long Gubrist Tunnel on the Zurich North Bypass (A1) is a neuralgic infrastructure on the Swiss motorway network. As a reaction to the permanent congestion in the twin tunnel that was commissioned in 1985, a third tube as well as ventilation and operating centres are being built. The article in tunnel 5/2018 explains the project’s characteristics and challenges with particular attention being paid to BIM modelling of the underground operating centre.

more
