Issue 06/2018

Content

Nachrichten | News

Japan

Hiroshima Heavyweight launches on Expressway Line 5 On September 18, 2018, a Robbins slurry machine, measuring 13.7 m in diameter, made its first cut into hard rock

On September 18, 2018, a Robbins slurry machine, measuring 13.7 m in diameter, made its first cut into hard rock for the Hiroshima Expressway Line 5 project in Japan. The launch at an urban jobsite was made possible by Onsite First Time Assembly (OFTA) of the TBM. The contractor, a joint venture of Obayashi-Taisei-Kosei, had a strict timeline of eight months to adhere to when it came to machine assembly. “This deadline was very important. After assembling the TBM, I think OFTA was appropriate for this project,” said Mr. Ryota Akai, Deputy Project Manager for the Obayashi JV.

more
Norway

Double Breakthrough on the Follo Line

After about 9 km each through tough gneiss, on September 11, 2018 the tunnel boring machines “Queen Eufemia” and “Queen Ellisiv” achieved a double breakthrough near the city center of Oslo. The Follo Line Project is currently Norway‘s largest infrastructure project and involves the construction of the country‘s longest railway tunnel. The two 20 km long tunnels connect Oslo with Ski further to the south. From 2021 they will shorten travel time for commuters by half.

more
Austrian Tunnel Day 2018

STUVA Research awarded Innovation Prize Water-permeable Annular Gap Material for Single-Shell Segment Linings

On 10 October 2018, the Austrian national committee of the International Tunnelling and Underground Space Association (ITA) awarded their innovation prize to the STUVA for the “development of a water-permeable annular gap material for single-shell drained segment linings”. During a ceremony as part of the Austrian Tunnel Day 2018, the trophy was handed to the STUVA and their research partners IMM Maidl & Maidl (Germany), Porr Bau GmbH (Österreich) and MC-Bauchemie Müller GmbH & Co. KG (Germany). The prize committee of the Austrian Tunnel Day regularly awards the prize to particularly creative developments in tunnelling.

more
Malaysia

MMC-Gamuda continues Underground Works of MRT Line 2 in Kuala Lumpur after Cost-Cuts of 21.5 %

On October 26, 2018 the Malaysian Ministry of Finance (MOF) announced that the Mass Rapid Transit Sungai Buloh-Serdang-Putrajaya (SSP) Line (MRT Line 2) project will be continued by MMC-Gamuda, after the company agreed to a larger cost reduction for the underground works. The Mass Rapid Transit (MRT) project is a strategic Government project which will increase connectivity of the Klang Valley’s public rail network.

more
Australia/Japan

JIM Technology purchases 50 % of Terratec Shares

Terratec has announced the incorporation of its business partner, JIM Technology from Japan, as shareholder of the company. Both companies have been working together for the last 8 years and delivered...

more

Hauptbeiträge | Main Articles

Geothermal energy

Web-based Application for the Investigation of thermally activated Tunnels

The equipment of infrastructure tunnels with absorbers for the extraction of heating or cooling energy is a consistent further development of the shallow geothermal hybrid systems in the field of ground engineering. The heat fluxes acting on a tunnel geothermal plant result from a complex interaction of the climatic conditions at the surface and inside the tunnel, the subsoil conditions and the operation of the geothermal plant. A prediction of possible heat extraction rates is thus only possible on the basis of transient simulations. In the article from tunnel issue 6/2018, a simulation application for the investigation of tunnel geothermal plants developed at the Institute of Geotechnical Engineering of the University of Stuttgart is presented, and the results of parameter studies regarding the heat extraction performance from a shallow urban transit tunnel are discussed.

more
Germany

Rudersdorf Tunnel: Future-oriented Principles DB Netz AG is planning two-track upgrade

The 100-year old, two-track Rudersdorf Tunnel between Siegen and Haiger restricts the route’s capacity owing to its small cross-section. Furthermore, the rail tunnel is requiring ever increasing maintenance. In a process lasting only seven months, a feasibility study was produced for the project, featuring six alternatives involving a more fundamental pre-planning process for the preferred option 3b “Construction of two new single-track tunnel tubes to the west of the existing tunnel including its decomissioning”. It has since passed the DB Netz AG’s “stress test”.

more

Modular Engineering Kit for Tunnel Construction

All over the world, private and freight traffic will continue to increase. According to the German Federal Statistical Office, even now more than half of all people live in cities and the surrounding areas. Globalisation and urbanisation are causing these infrastructure developments. As a result, people, raw materials and goods are being moved around more than ever before. Civil engineering is confronted with increasing demands; this includes structures for transport and utility networks. Tunnels and bridges are key elements. Such projects are normally tendered internationally. For business reasons, the bidding companies must be able to use reliable and exactly definable construction machines or formwork and scaffolding systems.

more

Baumaschinen | Construction Equipment

Fachtagungen | Conferences

Malaysia

First Chinese-Malaysian Tunnel Symposium held in Kuala Lumpur

„It is the first time ever that a symposium between the two ITA member nations China and Malaysia has been organized“, welcomed Dr. Teik Aun Ooi, Organizing Chairman of the SEASET 2018 (South East Asia Symposium & Exhibitions on the challenges and strategic solutions of high profile projects on Tunnels 2018) the more than 300 participants from China, Malaysia, the Southeast Asian Region and abroad in Kuala Lumpur, Malaysia. The joint symposium with a total of 18 lectures, delivered from well-known speakers, was organised by the China Civil Engineering Society (CCES) and the Institution of Engineers, Malaysia (IEM) on September 18 and 19, 2018.

more
InnoTrans 2018

International Tunnel Forum: Construction and Maintenance of the Transport Infrastructure

As part of the trade fair InnoTrans 2018 in Berlin, the German Research Association for Tunnels and Transport Facilities (STUVA) once again organised the “International Tunnel Forum” in the CityCube on the Messe Berlin exhibition grounds. STUVA managing director Dr.-Ing- Roland Leucker greeted about 130 guests on the two days to informative expert panels. The basic question discussed by both the experts on the podium and the members of the audience was the maintenance and extension of an efficient and modern infrastructure to serve the growing demand for mobility and ensure well organised goods transport with sufficient capacities for the present and the future.

more

STUVA-Nachrichten | STUVA News

Fachbücher | Technical Books

Compendium

Tunnelling Pocketbook 2019

The Tunnelling Pocketbook has been a reliable companion for clients, planners and practitioners for many years. The latest edition for 2019 provides practical findings and contains numerous related...

more
